SPECIFICATIONS
Brand Name: VIKYLIN
VIKYLIN Model: PG2046IRCS-P
Origin: Mainland China
High Definition: 4.0 Megapixels
Supported Operating Systems: Windows 7
Supported Operating Systems: Mac OS
Supported Operating Systems: Windows 8
Supported Operating Systems: Windows 10
Supported Operating Systems: Windows 98
Supported Operating Systems: Windows Vista
Supported Operating Systems: Windows 2000
Supported Operating Systems: Windows 2003
Supported Operating Systems: Windows XP
Supported Operating Systems: Windows 2008
Lens (mm): 4mm
Style: Bullet Camera
Connectivity: IP/Network Wired
Installation: Ceiling
Installation: Side
Minimum Illumination(Lux): 0.05lux @(F1.6)
Scene: Indoor and Outdoor
Color Night Vision: YES
Megapixels: 4MP
Video Compression Format: H.265
Video Compression Format: H.264
IR Distance(m): up to 30m (100ft)
Certification: CE
Certification: FCC
Dimensions (L x W x D)(mm): 9.29" x 4.33 x 2.91"
Color: WHITE
Alarm Action: Email Photo
Alarm Action: FTP Photo
Alarm Action: Local Alarm
is_customized: Yes
Model Number: PG2046IRCS-P
Supported Mobile Systems: Windows Mobile
Supported Mobile Systems: Android
Supported Mobile Systems: IOS
AI Functions: Motion Detection
IP Rating: IP67
Special Features: Waterproof / Weatherproof
Power Supply(V): 12 VDC/POE
Audio Output: Two Way Audio
Power Consumption(W): Max. 10.2 W
Sensor: CMOS
Shell Material: Metal
Power Supply: With POE
Viewing Angle : 170°
Image Sensor: 1/2.9" GC2063 CMOS
Min. Illumination: Color: 0.05lux @(F1.6), 0 lux with IR light
Shutter Speed: 1/10 s to 1/10,000 s
Slow Shutter: Yes
Day & Night: IR CUT Filter
Digital Noise Reduction: 3D DNR 2D DNR
WDR: 120dB
Angle Adjustment: Pan: 0° to 360°, tilt: 0° to 180°, rotate: 0° to 360°
Focal Length: Fixed focal lens,dual lens, 4 mm
Aperture: F1.6
Focus: Fixed
Focus Length & FOV: 4 mm, horizontal FOV: 170°, vertical FOV: 40°
Lens Mount: M12
White Light & IR Range: Up to 30 m
Smart Supplement Light: Yes
Video Compression: Main stream: H.265+/H.265/H.264 Sub-stream: H.265+/H.265/H.264
H.264 Type: High Profile/Main Profile/Base Profile
H.265 Type: High Profile/Main Profile/Base Profile
H.265+: High Profile/Main Profile/Base Profile
H.265 Type: Main Profile
Smart Event: Human detection
Basic Event: Motion detection
Linkage Method: Trigger recording: memory card, network storage, pre-record and post-record Trigger captured pictures uploading: FTP, HTTP, NAS, Email Trigger notification: HTTP, Email
Max. Resolution: 3840 x 1080
Main Stream: 50Hz: 20 fps 3840 x 1080 60Hz: 20 fps 3840 x1080
Audio Bit Rate: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
Sub-Stream: 50Hz: 20 fps 1280 x 360 60Hz: 20 fps 1280 x 360
Image Enhancement: WDR/HDR/3D DNR/2D DNR/HLC/BLC
Image Setting: Rotate mode, saturation, brightness, contrast, sharpness, and white balance adjustable by client software or web browser
SVC: H.264 and H.265 encoding support
Day/Night Switch: Day/Night/Auto/Schedule
Network Storage: Support local storage and NAS (NFS, SMB/CIFS)
Protocols: HTTP, RTSP, DHCP, FTP, NTP,ONVIF,P2P,SMTP,RTMP
Client: AJ_Client,AC18Pro,Videolink
Communication Interface: 1 RJ45 10M/100M self-adaptive Ethernet port
Built-in Microphone: Yes
Built-in Speaker: Power: 3W.MAX. Sound pressure lever:10cm: 100dB.
Reset Key: Yes
On-Board Storage: Built-in memory card slot, support microSD/microSDHC/microSDXC/TF card, up to 512 GB
Operating Conditions: -30 °C to +85 °C, humidity 95% or less (non-condensing)
Web Client Language: 14 languages: English,Russian,German,Italian,Turkish, Korean,Japanese,Traditional Chinese, Simple Chinese,Ukrainian,Portuguese,Croatian,Polish,Farsi
Power Consumption and Current: DC 12V, 1 A, max. 10 W ; 5.5X2.1 mm coaxial plug power PoE (802.3af, 36 V to 57 V), 0.35 A to 0.22 A, max. 12.5W
Protection Level: IP67-Each Camera has been tested waterproof
Material: Front cover:metal,body:metal,bracket:metal
